4x10 White Slim Design Aluminum Linear Slot Diffuser (Duct Opening)
4x10 White Slim Design Aluminum Linear Slot Diffuser (Duct Opening)
Buy more, save more
- Buy 3+ items Save 7%
- Buy 5+ items Save 10%
- Buy 10+ items Save 15%
Discount is automatically applied at checkout when eligible.
Couldn't load pickup availability
Will a 4x10 Slim Fit Your Space?
| Feature | Specification |
|---|---|
| Duct Opening Size | 4" × 10" |
| Neck Depth | 1-1/4" (Slim / Trimless) |
| Neck Size | 9-11/16" × 3-3/4" |
| Overall Face Size | 11-3/4" × 5-13/16" |
| Weight | [Chưa có dữ liệu] |
| Material / Finish | Alloy aluminum, white powder-coated (paintable) |
| Compatibility | Supply air, wall/ceiling/floor |
| Included | Diffuser, Deflector Bar, screws, manual guide card |
Installation
- Remove your old cover and confirm the duct opening measures 4" × 10".
- Confirm your duct depth allows only a shallow neck — that's what the Slim Design solves.
- Mount with the included screws through the hidden side holes.
- Use the Deflector Bar to set airflow direction.
Frequently Asked Questions
What's the difference between this and the standard 4x10 diffuser?
The Slim Design has a shallower 1-1/4" neck depth — it fits ducts too shallow for our standard-depth diffusers, without changing face size or airflow.
What size do I order — 4x10 or face size?
Order by duct opening size (4" × 10"). The face size (11-3/4" × 5-13/16") overlaps the opening.
Is this for supply air or return air?
Supply air, with adjustable airflow. For return air in this size, see our 4x10 return air grille.
Can I install this on a floor?
Yes — mounts on walls, ceilings, or floors.
Is a black finish available?
This Slim Design size is currently White only. See the standard-depth 4x10 Black Linear Slot Diffuser instead.
